Continuous spectrum awareness
Einsteinium RF emissions scanner
A network-connected spectrum-monitoring concept that continuously characterizes RF activity and flags signals that deviate from the expected background environment.
30 MHz–6 GHzFast wide/narrow scansNetwork alerting
Continuous spectrum awareness
Quiet, continuous monitoring for sensitive spaces
Installed in a boardroom, office or access-way, Einsteinium repeatedly sweeps the radio spectrum and compares observed energy with established background levels.
Detection workflow
- Continuous or scheduled spectrum sweeps
- Comparison against normal background RF levels
- Unknown or anomalous signals raise alerts to a networked monitoring system
- Designed for central notification of signal-detection events
Continuous spectrum awareness
Wideband characterization with narrowband follow-up
The design combines rapid broad-spectrum awareness with finer channel inspection and operator visualization.
Scanner capabilities
- 30 MHz to 6 GHz frequency range
- Wideband scan of 600 × 9.95 MHz channels in approximately 600 ms
- Narrowband scan of 600 × 23.3 kHz channels in approximately 600 ms
- Ethernet connectivity for centralized alerts
- Spectrum display, zoom, calendaring and waterfall visualization
Expansion concepts
- Central scanner with peripheral scanners for triangulation
- Back-end database lookup of known RF signatures
Discuss Einsteinium with Blackline.
Talk to Blackline about Einsteinium RF monitoring, characterization, alerting and deployment concepts.
Contact Blackline Systems
